Scheduling a Bosch Dishwasher in Home Assistant by Electricity Price
My tablet's Appliances view for a Bosch dishwasher and a Miele washing machine: a Cheapest tile picks the lowest price hour, a chart shows why.
Update, November 2026: I rebuilt the Appliances view on the wall tablet and rewrote this post to match. The dishwasher and washing machine status rows are larger. The washing machine now keeps a monthly count of washes, energy and cost, and a price chart under both cards shows what the Cheapest tile chooses between. The dishwasher runs on the HACS integration Home Connect Alt (home_connect_alt), so the entity names below are the current ones.
The dishwasher was the appliance I expected least from. It's a Bosch. It comes with the Bosch Home Connect app, which is fine but just another app. I connected it to Home Assistant mostly out of completeness.
Then I realised it exposes enough control to do something useful: start the wash in the cheapest electricity hour. The washing machine, a Miele, got the same treatment later. Both now sit in one view on the tablet.
What the dishwasher exposes
I switched from the official integration to the HACS one, Home Connect Alt, because it gives access to the machine's own delayed start. These are the entities I use. <id> stands for the appliance ID in the real names.
sensor.bosch_<id>_bsh_common_status_operationstate # Ready, Run, DelayedStart, Finished...
select.bosch_<id>_programs # Eco50 and the rest
select.bosch_<id>_bsh_common_option_startinrelative # the delay, e.g. 2:30
binary_sensor.bosch_<id>_bsh_common_status_remotecontrolstartallowed
switch.bosch_<id>_dishcare_dishwasher_option_halfload
switch.bosch_<id>_dishcare_dishwasher_option_variospeedplus
button.bosch_<id>_start_pause
button.bosch_<id>_stop
The one that matters is startinrelative. The machine takes a delay, not a finish time. I give it how long to wait, in half-hour steps, and then press start.
The dishwasher card
The status row at the top is the largest thing on the card. It says Ready, Starts 04:00, Done 15:40 or Finished, and the card background fills with a blue bar as the programme progresses. When the machine is ready, the second line shows the programme, the cheapest upcoming start and its price, and the price right now. In the screenshot at the top that reads "cheapest start tomorrow 04:00 · 2.30 kr/kWh (now 3.62)".
Under the status row there are three tiles, and they only exist while the machine is Ready:
- Cheapest shows the time and runs the scheduling script when I tap it.
- Start now starts at once and shows the current price, so I can compare it with the Cheapest time.
- Finish at is for the other way round. I set a time, an automation subtracts 90 minutes (it assumes Eco 50), rounds the delay down to half an hour and writes it to the machine. It only sets the delay.
Below the tiles are three chips: the programme, Half load and SpeedPerfect+. Two rows appear only when needed. A red Cancel row shows up while a start is scheduled or the machine runs. An amber "Remote start is off" row shows up when I forgot the button on the machine.
The Cheapest tile runs this script, trimmed here. The real one also checks that the machine is Ready and sends a notification with the start time and the price:
alias: Schedule dishwasher cheapest start
sequence:
- variables:
best_hour: >
{% set ns = namespace(price=999, hour='') %}
{% set prices = state_attr('sensor.energi_data_service', 'raw_today')
+ state_attr('sensor.energi_data_service', 'raw_tomorrow') %}
{% for p in prices %}
{% if as_timestamp(p.hour) > as_timestamp(now()) + 1800
and p.price < ns.price %}
{% set ns.price = p.price %}{% set ns.hour = p.hour %}
{% endif %}
{% endfor %}
{{ ns.hour }}
- action: select.select_option
target:
entity_id: select.bosch_<id>_bsh_common_option_startinrelative
data:
option: >
{% set half_hours = ((as_timestamp(best_hour) - as_timestamp(now())) / 1800) | int %}
{{ half_hours // 2 }}:{{ '30' if half_hours % 2 else '00' }}
- delay:
milliseconds: 800
- action: button.press
target:
entity_id: button.bosch_<id>_start_pause
The prices come from Energi Data Service (HACS), which has raw_today and, once tomorrow's prices are published, raw_tomorrow. The script looks at both, so the cheapest hour can be tomorrow. It skips the next 30 minutes, so it never picks the hour that is already running.
Two things it does not do. It picks the cheapest single hour, not the cheapest window for the whole programme. And because the delay is rounded down to half an hour, the machine can start up to 29 minutes before the cheap hour. For a wash that runs through the night, neither matters.
The washing machine card
The washing machine has the same status row and the same bar, which fills as the programme runs. The Cheapest and Start now tiles appear once I have chosen a programme on the machine.
It works differently from the dishwasher. I don't use a delayed start on the Miele. Cheapest only stores the planned start time in a helper (input_datetime.vaskemaskine_planlagt_start). An automation presses start at that time, if the machine is still waiting and remote control (MobileStart) is on.
Here is the catch. The Miele switches itself off after about 15 minutes. If the cheapest hour is hours away, the machine is usually dark when the time comes, and the automation can only send me a notification saying it could not start. The script warns me up front when the start is more than ten minutes out. In practice I choose the programme again closer to the time, or I use the washer when the cheap hour is near.

The three tiles at the bottom are new. Washes, Energy and Cost show the totals for this month, and Last wash shows the latest one: programme, kWh, kr and time. When a programme ends, an automation waits a minute, then adds the machine's own energy figure for that programme to three number helpers (vask_antal_denne_maaned, vask_kwh_denne_maaned, vask_kr_denne_maaned) and writes the last-wash line. On the 1st, just after midnight, it saves the old month to a text helper and zeroes the counters.
I show a month because one wash is too small to notice. October was 16 washes, 9.4 kWh and 14 kr. That is under a krone per wash, and I would never have felt it on a single wash. The number only means something added up.
The price is an estimate. The cost is the kWh times the price in the hour the programme ends, not the price of each hour it ran. For a wash of an hour or two that is close enough.
The price chart
The card under the dishwasher is the one that makes the rest readable. The top row shows the price now and the cheapest upcoming hour. Tap it and it opens my Energy view. Under it is an apexcharts-card that spans 48 hours from midnight: today in orange, tomorrow in green, with a dot on the cheapest hour of each day. The series are built from the same raw_today and raw_tomorrow attributes the script reads.

The status row, the Cheapest tile and the card header all run the same cheapest-hour query, so they always agree. The dots on the chart mark the cheapest hour of the whole day, including hours that have already passed. The tile only looks ahead. In the screenshot today's dot sits at 05:00, which is over, so the tile points at tomorrow's dot at 04:00.
The chart also tells me what a tile cannot. Tomorrow at 04:00 costs 2.30 kr/kWh against 3.62 right now, about 36 percent less. But the dip is wide, from midnight to about 05:00 the price barely moves, so starting an hour earlier or later costs nothing. The evening peak is above 6 kr/kWh at about 17:00. Seeing that is what makes me trust the single time on the tile.
Why this is worth the effort
Eco50 takes roughly 90 minutes to two hours. The price difference between the cheapest and most expensive hour of a typical Danish weekday is 1–3 DKK/kWh. At 0.8 kWh per cycle that's 0.80–2.40 DKK saved per wash. Not dramatic individually. Over 300 washes a year it adds up, and more importantly the grid is less stressed during peaks.
The real benefit is behavioural. I load the dishwasher when it's full, tap one tile, and don't think about it. The status row says when it starts and when it is done.
What doesn't work
Remote start has to be enabled on the machine's physical panel. There's a small icon for it on the display. If I forget, the start command does nothing. I've forgotten this enough times that the card now shows the amber "Remote start is off" row, but only when the machine is Ready.
Programme changes via HA only work before the machine starts. Once it runs, the programme chips and tiles disappear from the card, and the selects become read-only. That's a Bosch firmware limitation, not HA.
The finish notification is the other thing. When the programme passes 99 percent, an automation sends a notification and speaks a message on the kitchen speaker. I also have an alert ticker entry on the home screen, and "Dishwasher done, empty me!" stays there until someone acknowledges it. The status row adds "open the door to empty" while the door is still shut. Low-tech, but I actually empty it now instead of leaving it sitting there for three hours.
